A2K-4WT 4 Way T-Piece
The 4 Way T-Piece from Actisense saves you time, space and money on your NMEA 2000® installation.
The Actisense 4 Way T-Piece is for use where multiple drops or ‘ports’ are required from the NMEA 2000 backbone. It’s as quick and easy to install as a single T-Piece, uses less space than two individual T-pieces and costs less than four.
The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.
Stock: available
Available on backorder
Ordering Information
To order the 4-Way Instrument Drop, please use product code: A2K-4WT.
Tech Specs
| Electrical | |
| Rated Current | 4A |
| Rated Voltage | 60V DC |
| Mechanical | |
| Male Contact | Brass, gold plated |
| Female Contact | Phosphor bronze, gold plated |
| Contact Carrier | PA66 (30% Glass filled), black |
| Contact Polarisation | Standard M12 -“A”- polarisation |
| Mating Thread | M12 |
| Screw Cap | Brass, nickel plated |
| O-Ring Seal | Rubber, Black |
| Housing | TPU, flame retardant to UL94V-0, Halogen Free |
| Internal Housing Shield | Copper Foil |
| Weight | 105g |
| Approvals and Certifications | |
| NMEA 2000 Approved | |
| RoHS Compliant | |
| Protection | IP67 (when mated) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
