Blue Sea Systems 285-Series Surface Mount 60A Circuit Breaker
September 4, 2026On Sale
Original price was: 75.00€.70.00€Current price is: 70.00€.
The Blue Sea Systems 285-Series 60A panel mount circuit breaker is a marine-grade thermal circuit breaker designed to protect high-current DC electrical systems from overloads and short circuits. Combining circuit protection with manual switching capability, the Blue Sea Systems 285-Series 60A breaker is ideal for trolling motors, battery systems, inverters, windlasses, and other demanding marine applications.
Stock: available
Blue Sea Systems 285-Series Panel Mount Circuit Breaker – 60A
Overview
The Blue Sea Systems 285-Series 60A panel mount circuit breaker is a marine-grade thermal circuit breaker designed to protect high-current DC electrical systems from overloads and short circuits. Combining circuit protection with manual switching capability, the Blue Sea Systems 285-Series 60A breaker is ideal for trolling motors, battery systems, inverters, windlasses, and other demanding marine applications.
Main Features
- 60A continuous current rating
- Thermal bi-metal circuit breaker
- Manual reset with visible trip indicator
- Trip-free mechanism for enhanced safety
- Panel-mount design
- Functions as both circuit breaker and manual switch
- Ignition protected for gasoline-powered boats
- Weather-resistant construction
- Supports DC systems up to 48V
- Ideal for trolling motors, batteries, inverters and other high-current circuits
Specifications
| Specification | Value |
|---|---|
| Brand | Blue Sea Systems |
| Product Series | 285-Series |
| Product | Panel Mount Circuit Breaker |
| Part Number | 7084 |
| Distributor Part Number | M83-16-0010 |
| Current Rating | 60 A |
| Maximum Voltage | 48V DC |
| Circuit Breaker Type | Thermally Responsive Bi-Metal |
| Circuit Breaker Class | Type III – Manual Reset / Switchable / Trip-Free |
| Mounting Type | Panel Mount |
| Interrupt Capacity | 3000 A @ 48V DC |
| Terminal Stud Size | M6 |
| Maximum Terminal Torque | 5.65 Nm (50 in-lb) |
| Operating Temperature | -40°C to +85°C |
| Ignition Protection | SAE J1171 |
| Protection Rating | Weather Resistant (IP67) |
| Application | Marine DC Electrical Systems |
Package Contents
- Blue Sea Systems 285-Series 60A Panel Mount Circuit Breaker
- Mounting hardware
- Installation instructions
